3D Laser Scanning Glendenning

3D Laser Scanning Glendenning for Manufacturing and Industrial Projects

Blue 3D LiDAR scanner icon on a tripod with scanning waves

Glendenning is one of Western Sydney’s established industrial areas, supporting manufacturing, industrial machinery, steel fabrication, building products, warehousing and distribution. Its proximity to the M7 Motorway, M4 Motorway and Great Western Highway makes the suburb well positioned for businesses serving customers throughout Sydney and regional New South Wales.

Industrial facilities in Glendenning are constantly changing. Machinery is replaced, production areas are reorganised, safety guarding is added and warehouse operations expand. However, the drawings used to plan these changes are not always updated.

Hamilton By Design provides 3D laser scanning in Glendenning, together with reverse engineering, factory-layout development, mechanical drafting, machinery guarding and fabrication drawings. Our services help manufacturers and industrial operators understand their existing facilities before designing modifications, relocating equipment or commencing fabrication.

Glendenning’s Industrial Character

Glendenning contains a diverse mixture of industrial operations. Publicly identified businesses in the area are involved in reinforcing steel, sheet-metal fabrication, CNC machining, gearbox assembly, industrial drives, structural steel, aluminium building systems, refrigeration products and cold-chain logistics.

Typical operations include:

CNC machining, laser cutting and sheet-metal forming
Welding, structural-steel fabrication and assembly
Reinforcing bar, mesh and cage production
Gearbox, gearmotor and industrial-drive servicing
Machinery installation and maintenance
Building-product manufacturing and distribution
High-clearance warehousing and pallet storage
Refrigerated storage and cross-docking
Forklift, truck and pedestrian movements
Automated manufacturing and robotic equipment

These operations depend on accurate information about machinery, structures, access areas and services. When drawings are incomplete or outdated, even a relatively simple factory modification can become difficult to plan.

Capturing Existing Factory Conditions

A common industrial problem is the difference between the original drawings and the factory as it exists today. Machinery may have been moved, structural columns modified, platforms added or services installed without the original documentation being revised.

Hamilton By Design can use 3D laser scanning for engineering projects to capture the existing factory environment. Terrestrial LiDAR records millions of measured points across machinery, structures, walls, floors, services and surrounding access areas.

The registered point cloud can provide a reliable reference for:

Factory layouts and equipment arrangements
Machinery installation planning
Structural and service clearances
Conveyor and production-line modifications
Maintenance and equipment-removal access
Existing-condition plans, elevations and sections
As-built verification
Clash detection
Future factory upgrades

This reduces the dependence on manual measurements and provides project teams with a coordinated digital record of the areas relevant to the proposed work.

Machinery Layouts and Factory Modifications

Machinery layout development involves more than positioning equipment inside a building. The proposed arrangement must consider production flow, operator access, maintenance requirements, material movements, utilities, structural constraints and safe installation.

Hamilton By Design provides manufacturing layout design services for new equipment, factory expansions, production-line changes and machinery relocations.

Proposed machinery can be positioned within the scanned factory environment to review:

Clearances from walls, columns and existing equipment
Access for operators and maintenance workers
Forklift and pallet movements
Conveyor interfaces
Electrical, pneumatic and mechanical service routes
Installation and lifting requirements
Emergency and pedestrian access
Space required to remove motors, gearboxes and components
Potential clashes before equipment reaches the site

Identifying these issues during design is generally easier and less expensive than modifying equipment during installation.

Reverse Engineering Machinery and Components

Industrial machinery can remain in operation long after its original drawings have disappeared. Replacement components may no longer be supported by the original manufacturer, or the existing part may have been modified during previous repairs.

Hamilton By Design provides reverse engineering with 3D scanning to help recreate useful engineering information from existing equipment and components.

Depending on the size and required accuracy, the process may combine terrestrial LiDAR, handheld scanning and physical measurement. Critical features such as shafts, bores, threads, mounting faces and close-tolerance fits are independently measured rather than relying solely on the scanned surface.

Potential deliverables include:

Editable 3D CAD models
SolidWorks parts and assemblies
STEP or Parasolid models
General arrangement drawings
Manufacturing and fabrication drawings
Bills of materials
Dimensional comparison information
Replacement-component records

The objective is not simply to copy wear or damage. Engineering judgement is required to distinguish the intended geometry from deterioration, previous repairs and deformation.

Mechanical Engineering and Drafting Support

Hamilton By Design can assist Glendenning manufacturers with mechanical design for machinery modifications, equipment supports, guards, platforms, conveyors and fabricated assemblies.

Our mechanical drafting services can produce:

Factory and machinery layouts
General arrangement drawings
Part and assembly drawings
Fabrication and workshop drawings
Weldment details
Guarding drawings
Installation arrangements
Sections and elevations
Bills of materials
Revised as-built drawings
PDF, DWG, DXF and 3D CAD deliverables

Drawing practices may reference AS 1100.201 for mechanical engineering drawing, while structural and fabricated-steel work may require consideration of AS 4100, AS 3990, AS/NZS 1170 and AS/NZS 1554.1. The exact standards depend on the equipment, loads, materials, client specifications and intended use.

Using SolidWorks for engineering design allows scan information, measured geometry and engineering intent to be brought together in a structured 3D assembly before the fabrication drawings are prepared.

Machinery Guarding and Safe Access

Manufacturing equipment can expose workers to rotating shafts, belts, chains, gears, cutting tools, crushing zones, shear points and other hazardous movements. Poorly designed guards may also restrict inspection and maintenance, encouraging workers to remove or bypass them.

Hamilton By Design can assist with machinery-risk reviews, guarding concepts, access arrangements and fabrication documentation. Guard design may require consideration of the AS/NZS 4024 Safety of Machinery series, including risk assessment, guard construction and safety distances.

Our machine-guarding engineering information explains why guarding should form part of the engineering design rather than being treated as a later addition.

Hamilton By Design may assist with:

Fixed and removable guard designs
Perimeter guarding layouts
Access gates and maintenance openings
Guard-support frames
Conveyor guarding
Platforms, walkways and stairs
Maintenance-clearance reviews
Guard fabrication drawings
Residual-risk documentation

Platforms, walkways, stairs and ladders may require consideration of AS 1657. Electrical interlocks, emergency-stop circuits and safety-related control systems should be designed and validated by appropriately qualified electrical or control-system specialists.

Warehouse and Logistics Layouts

Glendenning’s proximity to major road networks makes warehousing and distribution an important part of the local industrial economy. These facilities commonly contain forklifts, pallet racking, loading docks, conveyors, cold-storage equipment and pedestrian work areas.

3D scanning can capture warehouse geometry, racking positions, columns, doorways, loading areas and existing traffic routes. This information can support concept layouts for:

Pallet-racking changes
Forklift aisle clearances
Pedestrian separation
Loading and unloading zones
Conveyor installations
Packing and dispatch areas
Equipment relocation
Truck-access planning

Relevant requirements may include AS 4084.1 and AS 4084.2 for steel storage racking, AS 2359 for powered industrial trucks and AS 2890.2 for commercial vehicle facilities. Specialist racking design, inspection and certification should be completed by an appropriately competent provider.

Retaining Engineering Data

The value of industrial scanning can continue after the immediate project is completed. Subject to agreed ownership, confidentiality, security and retention arrangements, Hamilton By Design can retain machinery geometry, registered factory scans, CAD models, equipment layouts, fabrication drawings and revision records.

This creates a more reliable starting point for later maintenance, machinery replacement or factory expansion. Rather than repeating the complete measurement process, future work can begin with an organised engineering record and update only the areas that have changed.

Frequently Asked Questions

What can 3D laser scanning capture inside a Glendenning factory?

LiDAR can capture visible machinery, structural steel, walls, floors, columns, conveyors, platforms, pipework and surrounding access areas. It cannot see through equipment or accurately capture hidden internal features without additional access or measurement.

Can the scan data be converted into SolidWorks or AutoCAD?

Yes. Relevant point-cloud areas can be converted into SolidWorks models, AutoCAD layouts, plans, elevations, sections, general arrangements and fabrication drawings. The required level of modelling should be agreed before work begins.

Can Hamilton By Design reverse engineer a machinery component without drawings?

Yes. Existing components can be scanned and physically measured to develop replacement CAD models and manufacturing drawings. Critical fits, bores, threads and mating features must be verified using appropriate measurement methods.

Can scanning help with machinery relocation?

Yes. The existing factory and proposed machinery can be reviewed together to check fit, access, maintenance space and installation constraints before relocation begins.

Does 3D scanning make machinery compliant?

No. Scanning provides accurate existing-condition information. Compliance requires an engineering assessment against the applicable legislation, standards, hazards and operating conditions.

What files can Hamilton By Design provide?

Depending on the project, deliverables may include E57, RCP, RCS, DWG, DXF, STEP, Parasolid, SolidWorks models, PDFs, general arrangement drawings, fabrication drawings and bills of materials.

Hamilton By Design combines industrial site experience with engineering-grade LiDAR scanning, reverse engineering, mechanical design and fabrication-ready drafting.

Whether the project involves a single machinery component, a production-line modification or a complete factory layout, accurate existing-condition information provides a stronger foundation for engineering decisions.

Contact Hamilton By Design to discuss 3D laser scanning, reverse engineering, machinery layouts or CAD drafting for an industrial project in Glendenning or elsewhere in Western Sydney.
