Making New Machinery Fit, Conveyors Fit and Production Upgrades Work – Before Fabrication Begins.
Hamilton By Design provides professional 3D LiDAR scanning for plant layouts, machinery installations and production upgrades in Kilsyth, Victoria, supporting manufacturers, engineering workshops and industrial facilities throughout Melbourne’s eastern industrial corridor.
Installing new machinery into an existing factory can present significant engineering challenges. Equipment must fit within available space, conveyors must align with existing production lines, chutes must connect to the correct transfer points, and maintenance access must remain practical.
Without accurate existing-condition information, seemingly straightforward plant upgrades can result in costly fabrication modifications, installation delays and production interruptions.
Hamilton By Design combines 3D laser scanning, point cloud processing, SolidWorks CAD modelling and mechanical engineering to help manufacturers plan upgrades around the actual dimensions of their facilities.
Our approach is straightforward:
Scan the Existing Plant → Model the Proposed Equipment → Check the Fit → Engineer the Upgrade → Prepare Installation Drawings
3D LiDAR Scanning for Industrial Plant Layouts in Kilsyth
Industrial manufacturing facilities often evolve over many years. Production equipment is relocated, conveyors are modified, machinery is replaced and additional services are installed.
As these changes accumulate, original factory layouts and engineering drawings may no longer accurately represent existing conditions.
3D LiDAR scanning captures the physical geometry of a manufacturing facility, providing a registered point cloud that can be used to develop an accurate spatial reference for engineering design.
We can capture:
- Existing manufacturing machinery and production equipment
- Conveyor systems, transfer points and chutes
- Structural steelwork, platforms and accessways
- Pipework, ducting and industrial services
- Floor levels, columns, walls and roof structures
- Equipment foundations and mounting locations
- Maintenance clearances and available installation space
This information allows proposed plant modifications to be developed within a digital representation of the existing facility.
New Machinery That Fits – Before It Arrives on Site
Purchasing new production equipment is a significant investment. However, confirming that a machine will physically fit inside an existing manufacturing facility involves more than checking its overall dimensions.
Engineers must consider equipment orientation, maintenance access, operator access, existing structures, services and connections to surrounding machinery.
Hamilton By Design uses 3D LiDAR scanning and mechanical CAD modelling to help verify the available installation space before equipment is delivered.
Where manufacturer CAD models are available, we can position the proposed machinery within the registered point cloud to assess its relationship with existing equipment.
This process can help identify:
- Insufficient equipment clearances
- Interference with existing structural steelwork
- Conflicts with pipework and electrical services
- Incorrect connection heights
- Restricted maintenance and operator access
- Potential installation and assembly constraints
The objective is to identify dimensional problems during engineering rather than during installation.
Conveyor Systems That Fit Existing Production Lines
Conveyor modifications are common during manufacturing upgrades, particularly where production capacity is being increased or new machinery is introduced.
However, integrating new conveyors into an existing factory can be challenging when equipment positions, floor levels and transfer heights are not accurately documented.
Hamilton By Design provides 3D scanning and mechanical engineering support for conveyor installations and modifications.
Our services can assist with:
- Conveyor relocation and replacement
- Conveyor centreline and elevation verification
- New conveyor connections to existing machinery
- Transfer point alignment
- Conveyor support steelwork
- Drive and maintenance access
- General arrangement and fabrication drawings
By combining existing plant scans with proposed conveyor CAD models, we can assess the equipment arrangement and identify potential clashes before fabrication.
Chutes That Fit – Transfer Points, Clearances & Wear Protection
Chutes and transfer systems must connect correctly to existing conveyors, processing machinery and surrounding structures.
Incorrect transfer point geometry can create installation difficulties, material handling problems and maintenance challenges.
Hamilton By Design provides mechanical engineering services for chute modifications, replacements and new installations.
Using 3D LiDAR scanning, we can capture existing conveyor discharge positions, receiving equipment, support structures and available space.
The resulting point cloud can support:
- Chute geometry development
- Transfer point alignment
- Chute replacement and modification
- Wear liner arrangements
- Access door positioning
- Support steelwork and connection details
- Maintenance and removal clearances
- Fabrication and installation documentation
Where required, the scanned geometry can be used to develop SolidWorks models of proposed chute arrangements.
The aim is to engineer chute systems that integrate with the existing plant, rather than relying on assumptions about site dimensions.
Production Line Upgrades Without Unnecessary Rework
Manufacturers continually seek opportunities to improve productivity, increase throughput, reduce manual handling and introduce new technology.
These improvements often involve modifications to existing machinery and production layouts.
3D LiDAR scanning provides a valuable engineering reference when planning production upgrades within operating facilities.
Hamilton By Design can assist with:
Production Line Reconfiguration
Capture existing equipment arrangements and develop alternative layouts for improved material flow, access and production efficiency.
New Machinery Integration
Position proposed equipment within existing plant geometry to assess installation requirements and connection points.
Conveyor & Material Handling Upgrades
Develop conveyor layouts, transfer arrangements and associated mechanical support structures.
Automation & Robotic Equipment
Provide existing-condition geometry to support the planning of automation cells, robotic equipment and associated guarding.
Maintenance & Access Improvements
Assess available space for platforms, walkways, machinery guarding and equipment maintenance.
Brownfield Plant Modifications
Support engineering modifications within established facilities where surrounding equipment and infrastructure must remain in place.
Scan-to-CAD – From Existing Plant to Engineering Design
Hamilton By Design uses FARO 3D LiDAR scanning equipment to capture industrial facilities and machinery.
Following scanning, the registered point cloud can be imported into engineering software to support modelling and design.
Our software capabilities include SolidWorks, AutoCAD, Autodesk ReCap and Navisworks workflows.
Depending on project requirements, deliverables may include:
- Registered 3D point clouds in E57 or RCP format
- Existing plant layout models
- SolidWorks mechanical assemblies
- Proposed equipment installation models
- General arrangement drawings
- Conveyor and chute fabrication drawings
- Equipment interface and clearance drawings
- Installation and modification documentation
By combining scanning and mechanical engineering, we can support projects from initial site measurement through to engineering documentation.
Reducing Installation Risk Through 3D Engineering
One of the greatest benefits of 3D LiDAR scanning is the opportunity to identify potential installation conflicts before equipment is fabricated or delivered.
Traditional site measurements may capture individual dimensions without documenting the full relationship between surrounding machinery, structures and services.
A registered 3D point cloud provides a more comprehensive spatial reference.
When combined with proposed equipment models, it can help engineers assess whether new installations will fit within existing plant constraints.
This can support:
- Reduced dimensional uncertainty
- Improved equipment positioning
- Earlier identification of potential clashes
- Better fabrication planning
- More accurate installation drawings
- Reduced risk of site rework
- Improved shutdown and installation coordination
While scanning does not eliminate every installation risk, it provides valuable information for better engineering decisions.
Supporting Kilsyth’s Manufacturing & Industrial Businesses
Kilsyth is part of Melbourne’s eastern manufacturing and industrial corridor, with businesses involved in machinery, fabrication, manufacturing, processing and industrial services.
Hamilton By Design supports engineering projects throughout Kilsyth and surrounding areas, including:
| Location | Plant Upgrade & Engineering Applications |
|---|---|
| Kilsyth | Factory layouts, machinery installations and production upgrades |
| Bayswater | Industrial machinery, conveyors and manufacturing plant modifications |
| Croydon | Mechanical engineering, fabrication and equipment upgrades |
| Lilydale | Production facilities, material handling and industrial plant layouts |
| Ringwood | Industrial equipment installations and facility modifications |
| Boronia | Manufacturing machinery and workshop layouts |
| Scoresby | Advanced manufacturing, automation and production equipment |
| Dandenong South | Heavy manufacturing, processing equipment and conveyor systems |
Our scanning and engineering services are also available throughout Melbourne, regional Victoria and interstate Australia.
Why Choose Hamilton By Design for Plant Upgrades?
Hamilton By Design combines practical mechanical engineering experience with industrial 3D scanning technology.
We understand that manufacturing equipment must do more than fit within a building. It must integrate with existing processes, provide suitable maintenance access and operate within the constraints of the surrounding plant.
Our services combine:
3D LiDAR Scanning – Capture existing plant geometry.
Point Cloud Processing – Establish a registered spatial reference.
SolidWorks CAD Modelling – Develop and position proposed equipment.
Mechanical Engineering – Design equipment modifications and assess mechanical interfaces.
Engineering Drawings – Prepare general arrangements, fabrication details and installation documentation.
This integrated approach is particularly valuable for brownfield manufacturing upgrades where existing equipment and structures limit the available installation space.
Frequently Asked Questions
Can 3D LiDAR scanning confirm whether new machinery will fit?
3D LiDAR scanning can provide existing-condition geometry that allows proposed machinery models to be checked against surrounding equipment, structures and services. Final installation verification may require additional dimensional checks and manufacturer information.
Can you design conveyors to connect with existing machinery?
Yes. Hamilton By Design can use scanning information to develop conveyor layouts, assess transfer heights and prepare mechanical engineering models and drawings.
Can you scan existing conveyors and design replacement chutes?
Yes. We can capture existing conveyor and transfer point geometry to support the development of replacement chutes, modifications and associated fabrication documentation.
Can you scan an operating factory?
Yes. Industrial scanning can often be undertaken while facilities remain operational, depending on access, safety requirements, equipment movement and site conditions.
Can you use CAD models supplied by machinery manufacturers?
Yes. Manufacturer CAD models can be incorporated into the existing plant geometry to support layout planning, clearance assessments and equipment integration.
Can you produce fabrication drawings following scanning?
Yes. Hamilton By Design can develop mechanical CAD models, general arrangement drawings and fabrication documentation as part of the engineering scope.
Planning a Machinery Installation or Production Upgrade in Kilsyth?
New machinery must fit. Conveyors must align. Chutes must connect. Production upgrades must work within the existing plant.
Hamilton By Design provides 3D LiDAR scanning, plant layout modelling, mechanical engineering and fabrication documentation to support manufacturing upgrades throughout Kilsyth and Melbourne’s eastern industrial corridor.
Whether you’re installing a single machine, modifying a conveyor system or upgrading an entire production line, we can assist with capturing existing conditions and developing practical engineering solutions.
